3 TECHNICAL DATA
0463 605 001
- 9 -
© ESAB AB 2018
3 TECHNICAL DATA
EMP 320ic (0700 300 991) EMP 255ic (0700 300 992)
Mains voltage 400 V ±10%, 3~ 50/60 Hz 400 V ±10%, 3~ 50/60 Hz
Primary current
I
max
MMA / I
eff
MMA 18.0 A / 11.4 13.0 A / 9.4 A
I
max
TIG / I
eff
TIG 16.0 A / 10.1 15.0 A / 6.3 A
I
max
MIG / I
eff
MIG 18.0 A / 11.4 17.0 A / 8.5 A
No-load power demand when in the energy-saving mode
U
in
400 V 68 W
Setting range
MMA 16 A / 20 V - 300 A / 32 V 16 A / 20 V - 255 A / 30 V
TIG 5 A / 10 V - 320 A / 23 V 5 A / 10 V - 255 A / 20 V
MIG 15 A / 15 V – 320 A / 34 V 15 A / 15 V – 300 A / 34 V
Permissible load at MMA
40% duty cycle 300 A / 32.0 V 255 A / 30.0 V
60% duty cycle 255 A / 30.0 V 170 A / 27.0 V
100% duty cycle 180 A / 27.0 V 130 A / 25.0 V
Permissible load at TIG
40% duty cycle 320 A / 23.0 V 255 A / 30.0 V
60% duty cycle 265 A / 21.0 V 215 A / 19.0 V
100% duty cycle 220 A / 19.0 V 170 A / 17.0 V
Permissible load at MIG
40% duty cycle 320 A / 23.0 V 255 A / 27.0 V
60% duty cycle 265 A / 27.0 V 200 A / 24.0 V
100% duty cycle 200 A / 24.0 V 160 A / 22.0 V
Efficiency 86% 86%
Power factor 0.87 0.87
Open-circuit voltage U
0
max
68 V 68 V
Open-circuit voltage U
0
max with VRD activated
35 V 35 V
Wire feed speed 1.3 – 20 m/min (50 – 800 in./min)
Wire diameter
Mild steel solid wire 0.8 – 1.2 mm (0.030 – 0.045 in.)
Stainless steel solid wire 0.8 – 1.2 mm (0.030 – 0.045 in.)
Flux-cored wire 0.8 – 1.6 mm (0.030 - 0.045 in.)
Aluminum 0.8 – 1.2 mm (0.030 – 0.045 in.)
Operating temperature -10 to +40 °C (+14 to +104 °F)
Transportation temperature -20 to +55 °C (-4 to +131 °F)
Bobbin size 100 – 300 mm (4 – 12 in.)
