ESAB FABRICATOR 211i
Manual 0-5450 7-5 ASSEMBLY PROCEDURES
7.05 Installing Cover Panel and Door Panel
1. Install Ground Screw, which connects the ground wire to the cover.
2. Install cover panel and door panel. Install Screws. Tighten screws.
Art # A-11363_AC
1
Install Screws
Tighten Screws Front & Rear
2
A-12948
