Automatic Provisioning using DHCP Option 66
The following steps will descript auto-provision by TFTP. You also can use
HTTP and FTP for auto-provision with our phones.
DHCP Server: (Microsoft Windows 2003 server)
1. Start up the “DHCP Management Console”;
2. Expand the DHCP scope which will contain the phones
3. Right-click on the “Scope Options” node
4. Select “Configure Options”
5. In the “General” tab, scroll down the list of options and identify the option
labeled “066 Boot Server Host Name”
6. Enable the “066 Boot Server Host Name” and enter the string value
according to the examples discussed previously
string value:
192.168.0.201(TFTP Server IP Address);
7. Click the “OK” button
IP Phone:
1. Input the IP Phone’s IP Address in browser;
2. Enter user and password with “root” then open the web page;
3. Click “Phone Maintenance” and select “Auto Provision”;
4. Select like as follows:
5. Click “Submit” to save it.
Auto-Provision via fixable TFTP/HTTP/HTTPS/FTP
Server
IP Phone:
1. Input the IP Phone’s IP Address in browser;
