Figure 12.4 Humidification flask
Humidification flask tubes are marked with number “1”and “2”. The same marking applies
for two outlets. Flask tubes must be connected to the outlets according to their number
(number “1” tube must be connected to the outlet marked with the same number).
Figure 12.5 Tubes connected to the flask
If no humidification is required, the U-looped silicone tube must be put from the
port marked ‘Outlet’ to the port below.
Fill the flask with sterile water up to the mark.
