Esco Multi-zone ART Workstation - Technical Specifications

MAW
®
User Manual Rev. 3.0
48
26 Specifications
Table 26.1 MAW, Multi-zone ART Workstation
®
specifications
Technical specifications
MAW-4D
MAW-6D
MAW-6D DUAL
MAW-6D MP
Work area dimensions (W x D
x H)
1260 x 500 x 710 mm
1870 x 500 x 710 mm
External dimensions without
support stand (W x D x H)
1340 x 640 x 1300
mm
1950 x 640 x 1300 mm
External dimension with “B”
type support stand (W x D x H)
1340 x 640 x 2160
mm
1950 x 640 x 2160 mm
Laminar airflow velocity
Average of 0.21 m/s or 41 fpm (± 20%)
Filter efficiency
>99.999% for particle size between 0.1 to 0.3 microns per IEST-RP-
CC001.3/H14 per EN 1822
Noise level (as per IEST)
≤ 47 dBA
≤ 48 dBA
Per-filter
Disposable and non-washable polyester fibers with 85% arrestance/EU3
rated
Heating system
Smart power injection electrical
heating, 9+1 zones
Smart power in-
jection electrical
heating, 2 x (9+1)
zones
Smart power in-
jection electrical
heating, 9+1
zones
Temperature accuracy
± 0.2
o
C
Temperature uniformity
± 0.2
o
C
Included advanced features
• Integrated humidification sys-
tem HS-1
• Surveillance system with data
logger
• AIO PC
• Heated glass stage
• Transmitted light source SC-1
(with bulb)
• 5 x PT1000 validation ports
• Dual integrated
humidification
system HS-1
• Surveillance
system with
data logger
• AIO PC
• 2 x heated glass
stage
• 2 x transmitted
light source SC-
1 (with bulb)
• 10 x PT1000
validation
ports
• Dual integrated
humidification
system HS-1
• Surveillance
system with
data logger
• AIO PC
• 2 x heated glass
stage
• 2 x transmitted
light source SC-
1 (with bulb)
• 5 x PT1000 val-
idation ports
Included accessories
• 1 x water bottle for HS-1, including
tubing
• 1 x sample carry tray
• 1 x humidified gas plastic cover
• 2 x water bottles for HS-1, includ-
ing tubing
• 2 x sample carry trays
• 2 x humidified gas plastic covers
Microscope provision
Provision for 1 microscope
Provision for 2
microscopes
Provision for 1
microscope and 1
inverted micro-
scope
