Eshed Robotec SCORBOT-ER 4pc - Handling Instructions; Repacking for Shipment

Repacking for Shipment
Be sure all parts are back in place before packing the robot.
ò The robot should be repacked in its original packaging for transport.
If the original carton is not available, wrap the robot in plastic or heavy paper. Put the
wrapped robot in a strong cardboard box at least 15 cm (about 6 inches) longer in all
three dimensions than the robot. Fill the box equally around the robot with resilient
packing material (shredded paper, bubble pack, expanded foam chunks).
Seal the carton with sealing or strapping tape. Do not use cellophane or masking tape.
Handling Instructions
Lift and carry the robot arm only by grasping the body or the base.
See Figure 2.
Do not lift and/or carry the robot arm by its gripper,
upper arm or forearm.
Do not touch the microswitches, cams or encoders.
Figure 2: Robot Arm Parts
