EST CM1 User Manual

Network Controllers Manual 13
Alphanumeric Display
A 40 character 2 line liquid crystal display provides system status and
program information.
08:53:18 AP 0000 DP 0000
PR
ESEN
T
TIME
AC
T
IVE
POIN
TS
D
ISABLED
P
O
IN
T
S
40 CHARACTER CUSTOM MESSAGE
[NWC-003.CDR]
CM1N Display
Status Codes
Fuz = Fuse
Gnd = Ground Fault
Acp = AC Voltage
Vlt = DC Voltage
Bat = Battery
Ext = Trouble
Int = Internal Fault (ZAS Card/Continuity Jumper, Display,
COMM Card, CPU Card)
Prn = Printer
1 = OK
0 = Fault
Communications Failures:
ComP = Primary Communications
ComS = Secondary Communications
ComE = External Command
NG = No Good
EN = Enabled
Status Codes w/ZAS-2
Com = Communications between ZAS-2 and CPU
Res = ZAS-2 Device Reset
ZAS = ZAS-2 Card Restsrt
Mpg = Mapping
Mpe = ZAS-2 Card Programming
Gnd = ZAS-2 Card Ground Fault
Lin = Class A Fault on ZAS-2 Circuit
Map = Map Fault
1 = OK (completed)
0 = Fault (in progress)
