Network Controllers Manual 3
Max. Current (riser current) 3.5 Amps DC
250 W @ 70 VRMS
250 W @ 25 VRMS
Max. Wire Size 14 AWG
Mounting One module footprint
CM1 firmware revision level may be determined by looking at the label
on the EPROM chip U3 on the CPU card.
Installation
Caution: Disconnect power before removing or installing modules.
The CM1 master control module requires one standard module
footprint and mounts directly below the PS4/8B power supply, using
#6 screws.
Plug Connections
P1 Connect a power supply cable assembly from connector P1 of
associated PS4B/8B power supply.
Cable assembly, 1 control module P/N 250057.
Cable assembly, 2 control modules P/N 250058.
Cable assembly, 3 control modules P/N 250059.
P2 Connect ribbon cable to P2 of associated PS4B/8B. Ribbon
cable assembly P/N 250054.
P3 Communications card, COMM-3 (P/N 130080) or COMM-3S
(P/N 130144)
P4 CPU card P/N 130073/1. Provides control functions for the
system. Verify firmware level required.
P5 First option card.
P6 Second option card. P5 MUST be utilized before using P6.
P7 Used to connect the LCD (CM1) display to the motherboard.
Jumpers J3 and J4 are to provide continuity when an associated
slot is not used and MUST be removed when the associated slot
has an option card installed.
