E200P Operation Manual
6
Chapter 2 Operation Example
2.1 Single-Step
2.1.1 Background
Now, There are a number of material, needs to be processed into workpiece, the
require as following:
 Depth of bending is 100.00mm
 Position of the backgauge is 80.00mm
 Distance of retracting is 5.00mm
 Time for the backgauge retract waiting is 2.00s
 Time for the block holds the pressure is3.00s
 Workpiece is 10.
2.1.2 Analysis
Parameter Setting
XP
80.00mm
YP
100.00mm
DX
5.00mm
HT
3.00s
DLY
2.00s
PP
10
Others
According to the actual situation to set.
2.1.3 Procedure
Step 1 When the E200P device is electrified, wait a few seconds into the SINGLE page
(Default page).
Step 2 According to the analysis, press the arrow keys and number keys to modify the
corresponding parameters, as shown in Figure 2-1.
