E200P Operation Manual
21
Appendix C Parameter Description
Parameter Default Range Unit Description
CONST
mm/inch 0 0~1 -

0: mm

1: inch
中文/English
0 0~1 -

0: 中文

1: English
Release Delay 0.50 s
The delay time for the slide
releasing the pressure after
bending.
Version - - -
The current software version
number.
TchIn PARA
X-tea. in 10.00 0~9999.999 mm/inch
When the teaching of X-axis
is enabling, the operator
assigns to the X-axis of a
correct value, to represent
the backgauge current
position.
Y-tea. in 10.00 0~9999.999 mm/inch
When the teaching of Y-axis
is enabling, the operator
assigns to the Y-axis of a
correct value, to represent
the slider current position.
CONFIG PARA.
YV5->NCRDY 0 0, 1 -

0: Disable, the function of
YV output is normal.

1: Enable, the function of
YV output is changed to
NCRDY output.
Jog Mode 0 0, 1 -

0: Semi.

1: Jog
SINGLE
XP
0~9999.999
mm/inch
Program position of X axle.
YP
0~9999.999
mm/inch
Program position of Y axle.
DX
0~9999.999
mm/inch
Retract distance of X axle.
HT 0~99.99 s
The interval time from LDP
signal to decompression
process.
