7
Single
: DestPosX Unit: mm
X= 10.00 Y = 10.00
XP = 80.00 YP = 100.00
DX = 5.00 HT = 3.00
DLY= 2.00 PP = 10
CP = 10 OPN= 0.00
XP = 80.00
Figure 2-1 Single-Step example configuration
Step 3 Press to run the machine, the device will enter the running page.
----End
2.2 Mutil-Step
2.2.1 Background
There is a number of sheet metal need for three bends, processing 50.
Requirements are follows:
The first bending: 50mm
The second bending: 100mm
The third bending: 300mm
2.2.2 Analysis
According to the process condition of workpiece and tool, analysis data are as
follows:
The first bending: Position of the backgauge is 50.00mm, Depth of bending is
85.00mm, Distance of retracting 5.00mm;
The second bending: Position of the backgauge is 100.00mm, Depth of bending is
85.00mm, Distance of retracting 5.00mm;
The third bending: Position of the backgauge is 300.00mm, Depth of bending is
85.00mm, Distance of retracting 5.00mm.
This operation will edit and save in the 2Program, when the device is power on, set
the following parameters in PROGRAM page.
PROGRAM
To Next Page
