20. List of all supported CVs
CV Name Description Range Value
1 Decoder address 1, LSB Lower 6 bits (bit 0 - 5) of the first decoder address for the outputs 1 to 4.
Is used in conjunction with CV 9 in order to store the address
1 - 63 1
3 Configuration output 1
(only SwitchPilot!)
Describes the properties of decoder output 1. 0 - 64 8
Function Description Value
Variable k83-compatible: output is active as long as the button at the control panel
is pressed.
0
Pulse mode
PECO
pulse mode for PECO-turnout drives. Reduces the sensitivity of the overload
protection
1
Pulse mode Duration of „On“-status: multiple of 65 msec. 2 - 31
Alternating Out A and Out B are alternately active blinker. Duration of „On“-status:
multiple of 130 msec.
32 - 63
Bi-stable k84-compatable: either Out A or Out B is active, variable. 64
4 Configuration output 2
(only SwitchPilot!)
Describes the properties of decoder output 2 0 - 64 8
Function Description Value
- as CV 3 -
5 Configuration output 3
(only SwitchPilot!)
Describes the properties of decoder output 3. 0 - 64 8
Function Description Value
- as CV 3 -
6 Configuration output 4
(only SwitchPilot!)
Describes the properties of decoder output 4. 0 - 64 8
Function Description Value
- as CV 3 -
7 Version number Interne Softwareversion des Decoders (SwitchPilot: 115, SwitchPilot Servo: 153) 115/153
8 Manufacturer’s ID Manufacturer’s ID by ESU. Writing value 8 results in a full factory reset of all CVs. - 151
