CV Name Description Range Value
9 Decoder address 1, MSB higher 3 bits (bit 6 - 8) of the first decoder address for the outputs 1 to 4. Used together with CV 1 to
store the address.
0 - 7 0
28 RailCom® configuration Activation and configuration of RailCom-functions 0,2 0
Bit Description Value
1 Data transfer on channel 2
No data transfer on channel 2
Data transfer on channel 2 permitted
0
2
29 Configuration register DCC-configuration settings for SwitchPilot 128 128
Bit Description Value 136
3 RailCom® communication
RailCom® communication is switched off 0
RailCom® communication is permitted 8
7 Decoder is DCC Accessory Decoder 128
(read only, cannot be reprogramed)
33 Function output status Current status of function outputs 1 to 4. 0 - 255 -
The status of the 8 feedback contacts is only valid if they are wired correctly to the turnout feedback
contacts. The value of CV 33 can be read and displayed via RailCom®.
Bit Description Value
0 Status output 1, input FB A 1
1 Status output 1, input FB B 2
2 Status output 2, input FB A 4
3 Status output 2, input FB B 8
4 Status output 3, input FB A 16
5 Status output 3, input FB B 32
6 Status output 4, input FB A 64
7 Status output 4, input FB B 128
