29
CV Name Description Range Value
34 „Zoom“-configuration Defining the outputs 1 - 4 that should show the „fade-in, fade- out“ effect when turned on
or off. „Zoom“ means slow fade-in or fade-out of the function.This enables you to simulate
the prototypical changeover of daylight signals, hence this function only makes sense for
daylight signals.
0 - 15 0 - 15
Bit Beschreibung Wert
0 „Zoom“-function active for output 1 1
1 „Zoom“-function active for output 2 2
2 „Zoom“-function active for output 3 4
3 „Zoom“-function active for output 4 8
35 Decoder address 2, LSB Lower 6 bits (bit 0 - 5) of the second decoder address for the outputs 5 and 6. Is used in conjunction
with CV 36 in order to store the address.
1-63 1
36 Decoder address 2, MSB Higher 3 bits (bit 6 - 8) of the second decoder address for the outputs 5 and 6. Is used in conjunction
with CV 35 in order to store the address. Value 8 in CV36 switches off the second address (factory
setting)
0 - 8 8
37 Servo 1,
rotation speed
Running time (speed) of servo 1 from one end position to the following. The running time is always a
multiple of 0.25 seconds: 1 = 0.25s,...,63 = 15.75s 24
0 - 63 15
38 Servo 1, Position „A“ Position A of Servo 1. Value indicates the pulse duration transmitted to the Servo. Value 0 = 1msec,...,
63 = 2msec.
0 - 63 24
39 Servo 1, Position „B“ Position B of Servo 1. Value indicates the pulse duration transmitted to the Servo. Value 0 = 1ms,..., 63
= 2ms.
0 - 63 40
40 Servo 2
rotation speed
like CV 37 0 - 63 15
41 Servo 2, Position „A“ like CV 38 0 - 63 24
42 Servo 2, Position „B“ like CV 39 0 - 63 40
List of all supported CVs
