Esu SwitchPilot 3 - Menu references

26
Menu references SwitchPilot 3 Servo
15. Menu references
No
Screen
Options
01
ADDRESS
Switch 1-4: 0001-0004
Switch 5-8: 0005-0008
Switch 1-4: Turnout numbers Servo 1 to 4
Switch 5-8: Turnout numbers Servo 5 to 8
02
ADDRESS MODE
Mode : RCN-213
Mode : RCN-213: Addressing as RCN-213.
Mode : ROCO : Addressing as ROCO.
03
SERVO 1 POSITION
Pos A : 24
Pos B : 40
Mode : Digital
Pos A : 0 .. 63: Servo 1 End position "A"
Pos B : 0 .. 63: Servo 1 End position "B"
Mode : Digital | Proportional
04
SERVO 1 SPEED
Speed A : 40
Speed B : 40
SPE REL : Delay On
Speed A : 0 .. 63: Adjustment speed on the way to "A"
Speed B : 0 .. 63: Adjustment speed on the way to "B"
SPE REL : Delay On | Delay Off
05
SERVO 1 BOUNCING
Bouncing: Pos A+B
Bounces : 0
Strength: 0
Bouncing: Disabled | Pos A | Pos B | Pos A+B
Bounces : 0 .. 31
Strength: 0 ..31
06
SERVO 2 POSITION
Pos A : 24
Pos B : 40
Mode : Digital
Pos A : 0 .. 63: Servo 2 End position "A"
Pos B : 0 .. 63: Servo 2 End position "B"
Mode : Digital | Proportional
07
SERVO 2 SPEED
Speed A : 40
Speed B : 40
SPE REL : Delay On
Speed A : 0 .. 63: Adjustment speed on the way to "A"
Speed B : 0 .. 63: Adjustment speed on the way to "B"
SPE REL : Delay On | Delay Off
08
SERVO 2 BOUNCING
Bouncing: Pos A+B
Bounces : 0
Strength: 0
Bouncing: Disabled | Pos A | Pos B | Pos A+B
Bounces : 0 .. 31
Strength: 0 ..31
