Esu SwitchPilot 3 - List of all supported CVs

33
Solenoid address & turnout numbers
List of all supported CVs
CV Name Description Range Value
1 Decoder address 1,
LSB
Lower 6 bits (bit 0 - 5) of the first decoder address for outputs 1 to 4. Used together with CV
9 to save the address.
1 - 63 1
7 Version number Internal software version of the decoder 201
8 Manufacturer ID Manufacturer number (ID) of ESU. Writing the value 8 resets all CV to the factory
setting.
- 151
9 Decoder address 1,
MSB
Upper 3 bits (bits 6 - 8) of the first decoder address for outputs 1 to 4.
Used together with CV 1 to save the address.
0 - 7 0
28 RailCom
Configuration
Activation and configuration of the RailCom function 0,2 2
Bit Description Value
1 Data transmission on channel 2
No data transmission on channel 2
Data transmission allowed on channel 2
0
2
29 Configuration
register
DCC configuration settings for the SwitchPilot 128,136 128
Bit Description Value 136
3 RailCom communication
RailCom communication is switched off 0
RailCom communication allowed 8
7 Decoder is DCC Accessory Decoder (solenoid) 128
(read only, cannot be changed)
35 Decoder address 2,
LSB
Lower 6 bits (bit 0 - 5) of the second decoder address for outputs 5 to 8. Used together with
CV 36 to save the address.
1 - 63 2
36 Decoder address 2,
MSB
Upper 3 bits (bits 6 - 8) of the second decoder address for outputs 5 to 8.
Used together with CV 36 to save the address.
0 - 7 0
37 DCC turnout
addressing
Calculation of the turnout numbers from the decoder address 0,1 0
Bit Description Value
0 DCC turnout addressing compliant with RCN-213
DCC turnout addressing for ROCO centers
0
1
