Esu SwitchPilot 3 - Page 34

34
List of all supported CVs
CV Name Description Range Value
43 Pulse configuration Options for generating the servo pulses. This applies equally to all outputs. 0 - 7 0
Bit Description Value
0 Always generate a servo pulse
Generate servo impulse only after the first command 1
1 Never switch off the servo pulse
Switch off the servo pulse approx. 1 second after reaching the end position 2
2 Always supply power to the servo
Only supply the servo with power when it is to be moved 4
44 Function Mapping
„F1”
Servos that switch at turnout number 1. 0 - 255 1
Bit Description Value
0 Servo 1 1
1 Servo 2 2
2 Servo 3 4
3 Servo 4 8
4 Servo 5 16
5 Servo 6 32
6 Servo 7 64
7 Servo 8 128
45 Function Mapping
„F2”
Servos that switch at turnout number 2. 0 - 255 2
Bit Description Value
- as CV 44 -
46 Function Mapping
„F3”
Servos that switch at turnout number 3. 0 - 255 4
Bit Description Value
- as CV 44 -
47 Function Mapping
„F4”
Servos that switch at turnout number 4. 0 - 255 8
Bit Description Value
- as CV 44 -
48 Function Mapping
„F5”
Servos that switch at turnout number 5. 0 - 255 16
Bit Description Value
- as CV 44 -
