List of all supported CVs
List of all supported CVs
CV Name Description Range Value
49 Function Mapping
„F6”
Servos that switch at turnout number 6. 0 - 255 32
Bit Description Value
- as CV 44 -
50 Function Mapping
„F7”
Servos that switch at turnout number 7. 0 - 255 64
Bit Description Value
- as CV 44 -
51 Function Mapping
„F8”
Servos that switch at turnout number 8. 0 - 255 128
Bit Description Value
- as CV 44 -
112 Servo 1
speed A
Running time (speed of rotation) towards end position “A”. Running time is a multiple of 0.25
seconds: 1 = 0.25s, 63 = 15.75s
0 - 63 15
113 Servo 1
End position A
End position A of servo 1st value indicates the pulse length that is sent to the servo. 0 - 63 24
114 Servo 1
End position B
End position B of servo 1st value indicates the pulse length that is sent to the servo. 0 - 63 40
115 Servo 1
speed B
Running time (speed of rotation) towards end position „B”. Running time is a multiple of 0.25
seconds: 1 = 0.25s, 63 = 15.75s
0 - 63 15
116 Servo 1
number of bounces
Number of bounces, if bouncing is active 0 - 31 0
117 Servo 1
Strength bouncing
Strength of the bouncing, if bouncing is active 0 - 31 0
118 Servo 1
Options
Settings for servo 1 128,136 128
Bit Description Value 136
0 Rocking switched off when position „A” is reached
Rocking switched on when position “A” is reached 1
1 Rocking switched off when position „B” is reached
Rocking switched on when position „B” is reached 2
2 Operating mode: digital mode (servo always stops at „A” or „B”)
Operating mode: Proportional mode (servo runs as long as the button is pressed) 4
3 SwitchPilot Extension: The assigned relay is switched immediately
SwitchPilot Extension: The assigned relay is switched with a delay 8
