Esu SwitchPilot 3 - Page 7

7
Operating modes
Figure 2: Digital mode
keyboard
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
time
on
off
RED
ON
RED
OFF
GREEN
ON
GREEN
OFF
Turns to „A“ „Speed A“ Pos „A“
Turns to „B“ „Speed B“
Pos „B“
Figure 3: Proportional mode
keyboard
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
time
on
off
RED
ON
RED
OFF
GREEN
ON
GREEN
OFF
Turns to „A“
Stands still
Turns to „B“
Stands still
