Footplates
Adjust the height to support the feet and so that
the thighs rest against the seat cushion.
For outdoor use the footplates should be raised
4 – 5 cm above the ground.
Tipping risk!
Never stand on
the footplates
Angle adjustment
Adjust the angle of the foot supports so that your ankles
are at a 90° angle.
Adjusting the height
Fully loosen the locking handle on the leg support. Remove
the screw. Set the height. Replace the screw and handle.
Tighten securely.
Arm support (adjustment)
• Loosen the screws on the inside of the supportive plate.
• Move the arm support up or down to the desired height
and tighten the screws.
• Loosen the screws on the underside of the arm support
cushion to adjust the length of the cushion.
• Correctly adjusted arm supports provide upper body
support. The arm support plate should be approximately 5
mm taller than the elbow when bent at an angle of 90°.
5 mm
3 mm
Calf/heel strap
• Adjust the length so that the centre of the feet are placed
on the footplates.
Seating comfort settings
User manual
