1
4
2 3
5 mm
30-70 mm
1 2 3
4 5
2 Nm
5 mm
The calf support is height and depth-settable.
1. Loosen the screw, adjust the height of the calf support and
tighten.
2. Loosen the screw that keeps the calf support in place.
3. Remove the screw and select the depth.
4. Insert the screw and tighten slightly. The calf support must be
movable.
Never stand on the footplates as there is a risk
of tipping!
Don’t lift the chair by the leg supports.
Always make sure that the screw and footplate
knob are installed even if the footplate is not used.
8. Readjustments
Elevating leg support with calf support
Anti-tips
The anti-tips are foldable, turnable and height-settable.
Bear in mind the risk of tipping.
Always check the positioning of the anti-tips.
