1
2
3
54
5 mm
3 mm
The trunk support is height and depth-adjustable
and removable.
1. Loosen the screw on the side to adjust the trunk
support depth.
2. Loosen the screws on the rear to:
3. adjust the trunk support height
4. Loosen the knob on the rear to:
5. adjust the sides of the trunk support.
6. remove the trunk support from the chair.
9. Accessories - adjustment, handling
Trunk support
