The seat depth can be adjusted in three fixed positions by reposi-
tioning the back chassis and the rear seat plate.
1. Tilt the back support upwards.
2. Tilt the seat as far back as possible and remove
the seat cushion.
3. Lift the seat plates off by loosening the screws
on the bottom of the seat chassis.
4. Twist the anti-tips to one side.
Remember that the wheel positions might also
need to be re-adjusted to achieve correct balance
in the chair.
Bear in mind the risk of tipping.
Always check the positioning of the anti-tips.
13 mm 5 mm
7. Settings
Seat depth, rear
