1
2 3
1. Loosen the screws on both sides of the seat.
2. Adjust the seat depth by pulling the seat out or
by pushing it in.
3. The front seat depth can be adjusted by up to 7 cm.
Do not pull the seat out further than the "max. line".
4. Tighten the retaining screws
Bear in mind the risk of tipping.
Always check the positioning of the anti-tips.
5 mm
7. Settings
Seat depth, front
