www.ets-lindgren.com EMCenter Controls and Connectors
21
Slot 9—Dedicated to the power supply card. The power supply card
also provides a connection for an external interlock.
Interlock Safety interlock connection that provides two
floating contacts which require shorting for the
EMCenter to operate.
Use the supplied connector (6.3 mm 1/4-in
stereo jack) to wire to the emergency switch of
your site. Connect the tip and middle pin.
Mains Inlet Used to connect to the mains power to the
EMCenter.
This IEC inlet holds a primary fuse. Always use
the correct fuse when replacing the fuse.
The main power switch is also located on the
IEC inlet.
