1.0 Introduction
For flexible configuration of an EMC test facility and fully-automated testing, the
ETS-Lindgren EMCenter™ Modular RF Platform provides space for up to
seven plug-in cards in a 3U, 19-inch rack mount enclosure. The EMCenter can
also be used as a desktop unit.
The EMCenter is available in the following configurations:
 Model 7000-001: 7-slot EMCenter Modular RF Platform
 Model 7000-010: 7-slot EMCenter Modular RF Platform with GPIB
 Model 7000-011: 2-slot EMCenter Modular RF Platform with GPIB
The slots can contain a user-defined combination of these ETS-Lindgren cards:
EMSwitch™, EMPower™, EMControl™, and EMSense™. When installed, each
card is automatically recognized, initialized, and ready for use. For more
information on the cards, see EMCenter Plug-In Cards (Optional) on page 8.
The EMCenter is configured and controlled using the 7-in widescreen color
thin-film transistor (TFT) touchscreen on the front panel. Additionally, the
EMCenter may be controlled from a computer using these software products:
 ETS-Lindgren TILE!™ (Totally Integrated Laboratory Environment)
 ETS-Lindgren EMQuest™ Data Acquisition and Analysis Software
 Other test automation software
