ETS STARPOWER 548 - Assembly: Canopy Adapter Arms

6
Installation - Assembly Procedures
27330-01A
Attach adapter arms
to canopy arms using
two adapter gussets
and six bolts and nuts.
Parts needed:
Canopy
2 - Canopy Adapter Arms
4 - Adapter Gussets
12 - 3/8 x 1 1/4” hex-socket bolts
12 - 3/8” self-locking hex nuts
ADAPTER ARM
ADAPTER
GUSSET
CANOPY ARM
