Operating Instructions
Transponder-Coded Safety Switch CET.-AS-…
24
(Translation of the original operating instructions) 2113689-04-07/19
13. Technical data
NOTICE
If a data sheet is included with the product, the information on the data sheet applies.
13.1. Technical data for safety switch CET.-AS-…
Parameter Value Unit
min. typ. max.
General
Material, ramp Stainless steel
Material, safety switch housing Die-cast aluminum
Installation orientation Any (recommendation: switch head downward)
Degree of protection IP67 (screwed tight with the related mating connector)
Safety class III
Degree of contamination 3
Mechanical life 1 x 10
6
operating cycles
Ambient temperature at U
B
-20 - +55 °C
Actuator approach speed, max. 20 m/min
Locking force F
max
6,500 N
Locking force F
Zh
(incl. safety margin acc. to GS-ET-19) F
Zh
= F
max
/1.3 = 5,000 N
Weight Approx. 1.0 kg
Degrees of freedom (actuator in recess) X, Y, Z X and Y: ± 5; Z: ± 4 mm
Connection (depending on version) Plug connector M12, 4-pin
Resilience to vibration Acc. to EN 60947-5-2
EMC protection requirements Acc. to EN IEC 60947-5-3
Ready delay - - 1 s
Risk time - - 400 ms
Switch-on time - - 500 ms
Solenoid
Auxiliary voltage 24 +10%/-15% (PELV) V DC
Current consumption with auxiliary voltage 400 mA
Duty cycle 100 %
AS-Interface data EA code: 7 ID code: B
Total current consumption - - 30 mA
Valid AS-Interface addresses 1 - 31
AS-Interface inputs Acc. to AS-Interface Safety at Work
Door monitoring contact D0, D1
Solenoid monitoring contact D2, D3
AS-Interface outputs
Guard locking solenoid D0, 1 = solenoid energized
Red LED D1, 1 = LED on
Green LED D2, 1 = LED on
Reliability values acc. to EN ISO 13849-1
Mission time 20 years
Monitoring of guard locking and the guard position Head downward or horizontal Head upward
Category 4 3
Performance Level (PL) e e
PFH
D
3,1 x 10
-9
/ h 4,29 x 10
-8
/ h
Control of the guard locking by ASi Bit D0
Category B
Performance Level (PL) b
PFH
D
4.23 x 10
-6
/ h
