EUCHNER CET-AS Series User Manual

25
2113689-04-07/19 (Translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CET.-AS-…
EN
13.1.1. Typical system times
Please refer to the technical data for the exact values.
Switch-on time of safety outputs: The max. reaction time t
on
is the time from the moment when the guard is locked to
the moment when the safety outputs switch on.
Risk time according to EN 60947-5-3: If an actuator moves outside the operating distance, the safety outputs (OA
and OB) are deactivated at the latest after the risk time.
13.2. Dimension drawing for safety switch CET.-AS-…
42
67,2
30
16
130
167
28
25
25
11
5
34
15
74,5
±4 mm
<15>
43,6
52
91,2
CET.-AR...CRA...
CET.-AR...CDA...
20
11,3
SW
19
75
7
(15)
41
15
M12
21,7
22
Plunger
Auxiliary
release
LED 2
OUT D
(green)
LED 1
(red)
∅6.5
For M6 screw
DIN1207/ISO4762
Basic position for
escape release
Release by pressing
With escape release
ASi
(green/
red)
STATE
(green/
red)
