Section 7: Channel Function Enhancements
Euphonix CS3000/2000 MixView 3.0 Software Supplement 7 - 53
There are some additional mono-in variations which bear mentioning at this
time. From the Aux Status menu, press [F3] to lock the pan control signal at
the center:
F3F1 F2 F4
An additional mode is accessible from this Level/Pan Mode menu. This Mono
mode sums all inputs and outputs, disables the upper control of the A/B and
C/D aux sends and is included here only for backward title compatibility with
earlier versions of software.
Press [F2] to select Mono mode:
F3F1 F2 F4
In this exercise, we will setup channel 16’s aux send A & B as a stereo in/
stereo out level and pan feed.
Press channel 16’s aux A/B block attention key to display the Aux Status menu
and confirm that console attention is directed to aux send A:
F3F1 F2 F4
Press the [*ST] key followed by [F3] (Yes) to change to stereo linked mode:
F3F1 F2 F4
F3F1 F2 F4
The most commonly used stereo mode is Stereo Balance mode.
Exercise 4
Stereo Balance mode
Mono Pan Center
Locked Mode
Mono mode
SIDE NOTE:
This mode is rarely used and
should not be confused with the
similarly displayed Mono
Independent mode.
16AB-> MnPan Ctr Ind?
16AB-> Mono - - - Ind?
16A-> ON pre
AB Stereo Aux ? Yes [No]
16AB->
*
Stereo Bal Ind?
