Euresys Coaxlink Mono - DIN 1 Coaxpress Host Connector

23
DIN 1 CoaXPress Host Connector
Applies to:
Connector description
Property Value
Name CoaXPress Host
Type DIN 1.0/2.3 75 Ohms coaxial female receptacle
Location Card bracket
Usage CoaXPress Host Interface
Pin assignments
Pin Signal Usage
Inner CXP_A CoaXPress Host Connection A
Outer GND Ground
Coaxlink Hardware Manual
