C2C-Link Connector
Applies to:
Connector description
Property Value
Name C2C-Link
Type 6-pin dual-row 0.1" pitch pin header with shrouding
Location Printed circuit board
Usage Card-to-card link
Pin assignments
Pin Signal Usage
1 GND Ground
2 CSync1 Card-to-card synchronization bus – Signal 1
3 GND Ground
4 CSync2 Card-to-card synchronization bus – Signal 2
5 GND Ground
6 CSync3 Card-to-card synchronization bus – Signal 3
