3.4. PCI Express Power
Power requirements per product
The following table provides the typical PCI Express power consumption for each product when
it operates under the following conditions:
□ Acquiring image data using all CoaXPress Host Interface connections operating at their
maximum speed
□ Delivering image data on the PCI Express configured for the largest link width and the
highest link speed
□ Operating @25°C [77 °F] ambient temperature and nominal supply voltages
Product +12 V +3.3 V Total Units
1630 Coaxlink Mono 7.2 2.1 9.3 W
1631 Coaxlink Duo 8.7 2.7 11.4 W
1632 Coaxlink Quad 9.6 2.5 12.1 W
1633 Coaxlink Quad G3 13 3.8 16.8 W
1633-LH Coaxlink Quad G3 LH 13 3.8 16.8 W
1635 Coaxlink Quad G3 DF 13 3.8 16.8 W
1637 Coaxlink Quad 3D-LLE 13 3.8 16.8 W
3602 Coaxlink Octo 11.8 4.2 16 W
3603 Coaxlink Quad CXP-12 9.8 7.3 17.1 W
3620 Coaxlink Quad CXP-12 JPEG 11.8 6.3 18.1 W
3621-LH Coaxlink Mono CXP-12 LH 8.5 3 11.5 W
3622 Coaxlink Duo CXP-12 10.5 4.3 14.8 W
Voltage requirements
Parameter Min. Typ. Max. Units
+3.3 V voltage 3.0 3.3 3.6 V
+12 V voltage 11.0 12.0 13.0 V
