Micro-BNC 2 CoaXPress Host Connector
Applies to:
Connector description
Property Value
Name CoaXPress Host
Type 2 x Micro-BNC 75 Ohms coaxial receptacles
Location Card bracket
Usage CoaXPress Host Interface
Pin assignments
Pin Signal Usage
Inner1 CXP_A CoaXPress Host Connection A
Outer1 GND Ground
Inner2 CXP_B CoaXPress Host Connection B
Outer2 GND Ground
