3.2. PCI Express Interface
Specification of the PCI Express Interface
The PCI Express Interface implements a PCIe end-point interface and provides electrical power to
the Coaxlink card.
PCI Express end-point type per product
Product Type
1630 Coaxlink Mono "4-lane Rev 2.0 PCIe end-point" on page68
1631 Coaxlink Duo "4-lane Rev 2.0 PCIe end-point" on page68
1632 Coaxlink Quad "4-lane Rev 2.0 PCIe end-point" on page68
1633 Coaxlink Quad G3 "4-lane Rev 3.0 PCIe end-point " on page67
1633-LH Coaxlink Quad G3 LH "4-lane Rev 3.0 PCIe end-point " on page67
1635 Coaxlink Quad G3 DF "4-lane Rev 3.0 PCIe end-point " on page67
1637 Coaxlink Quad 3D-LLE "4-lane Rev 2.0 PCIe end-point" on page68
3602 Coaxlink Octo "8-lane Rev 3.0 PCIe end-point" on the next page
3603 Coaxlink Quad CXP-12 "8-lane Rev 3.0 PCIe end-point" on the next page
3620 Coaxlink Quad CXP-12 JPEG "8-lane Rev 3.0 PCIe end-point" on the next page
3621-LH Coaxlink Mono CXP-12 LH "4-lane Rev 3.0 PCIe end-point " on page67
3622 Coaxlink Duo CXP-12 "4-lane Rev 3.0 PCIe end-point " on page67
