Power Transmitting Unit
The Power Transmitting Unit provides 17 W* of 24 V DC power per connection, over-current
protection (OCP) and PoCXP device detection as specified by the CoaXPress Standard.
Power Transmitting Unit Specification
Parameter Min. Typ. Max. Unit
DC output voltage 22 24 26 V
Available output power 17* W
OCP holding current 790 mA
OCP nominal trip current 5 A
Device detection sense resistance 4.7 kΩ
NOTE
(*) 25 W for 3621-LH Coaxlink Mono CXP-12 LH
NOTE
The above specification applies over the whole operating temperature range
of the Coaxlink card.
See also: Refer to Power Over CoaXPress in the Functional Guide
