CXP-6 Host Transceiver
Applies to:
The Host transceiver implements a high-speed cable receiver and a low-speed cable driver for
CXP-6 speeds.
It fulfills the electrical specification of the CoaXPress 1.1 standard. Namely:
● The cable receiver requirements for the high-speed connection described in Table 2 of the
Annex B of the CoaXPress Standard 1.1
● The cable driver requirements for the low-speed connection described in Table 3 of the
Annex B of the CoaXPress Standard 1.1
Host Transceiver Specification
Parameter Conditions Min. Typ. Max. Unit
High-speed connection bit rate 1.25 6.25 GT/s
Low-speed connection bit rate 20.833 MT/s
Max. cable length
BELDEN 1694 @ 1.25 GT/s 130 m
BELDEN 1694 @ 2.5 GT/s 110 m
BELDEN 1694 @ 3.125 GT/s 100 m
BELDEN 1694 @ 5 GT/s 60 m
BELDEN 1694 @ 6.25 GT/s 40 m
