Pin Signal Usage
16 +3V3 +3.3 V Power
17 IOEXT08 I/O Extension #8
18 GND Ground
19 IOEXT09 I/O Extension #9
20 12V 12V Power
21 IOEXT10 I/O Extension #10
22 GND Ground
23 IOEXT11 I/O Extension #11
24 12V 12V Power
25 IOEXT12 I/O Extension #12
26 GND Ground
