32
Pin Signal Usage
16 IOUT12+ Isolated contact output #12 – Positive pole
17 TTLIO12 TTL input/output #12
18 GND Ground
19 DIN11- High-speed differential input #11 – Negative pole
20 DIN11+ High-speed differential input #11 – Positive pole
21 IIN12- Isolated input #12 – Negative pole
22 IOUT11- Isolated contact output #11 – Negative pole
23 IOUT11+ Isolated contact output #11 – Positive pole
24 GND Ground
25 TTLIO11 TTL input/output #11
26 +12V +12 V Power output
Coaxlink Hardware Manual
