35
Pin Signal Usage
16 MIO13 Single-ended I/O #13 or differential I/O #13 positive pole
17 MIO17 Single-ended I/O #17 or differential I/O #17 positive pole
18 MIO20 Single-ended I/O #20 or differential I/O #19 negative pole
19 MIO02 Single-ended I/O #2 or differential I/O #1 negative pole
20 MIO01 Single-ended I/O #1 or differential I/O #1 positive pole
21 MIO08 Single-ended I/O #8 or differential I/O #7 negative pole
22 MIO12 Single-ended I/O #12 or differential I/O #11 negative pole
23 MIO11 Single-ended I/O #11 or differential I/O #11 positive pole
24 MIO16 Single-ended I/O #16 or differential I/O #15 negative pole
25 MIO15 Single-ended I/O #15 or differential I/O #15 positive pole
26 +12V +12 V Power output
Coaxlink Hardware Manual
