Pin Signal Usage
16 MIO12 Single-ended I/O #12 or differential I/O #11 negative pole
17 MIO13 Single-ended I/O #13 or differential I/O #13 positive pole
18 MIO14 Single-ended I/O #14 or differential I/O #13 negative pole
19 MIO15 Single-ended I/O #15 or differential I/O #15 positive pole
20 MIO16 Single-ended I/O #16 or differential I/O #15 negative pole
21 MIO17 Single-ended I/O #17 or differential I/O #17 positive pole
22 MIO18 Single-ended I/O #18 or differential I/O #17 negative pole
23 MIO19 Single-ended I/O #19 or differential I/O #19 positive pole
24 MIO20 Single-ended I/O #20 or differential I/O #19 negative pole
25 +12V +12 V Power output
26 +12V_RTN Ground
Coaxlink Hardware Manual
