PCIe products with four PoCXP
Applies to:
Parameter Conditions Min. Typ. Max. Units
DC input voltage 11 12 13 V
DC input power for I/O 12 W I/O output power 0 12 W
DC input power for PoCXP
68 W total PoCXP output power
74 W
PoCXP output voltage 23 24 25 V
Power conversion efficiency 92.5 %
PCIe products with eight PoCXP
Applies to:
Parameter Conditions Min. Typ. Max. Units
DC input voltage 11 12 13 V
DC input power for I/O 12 W I/O output power 0 12 W
DC input power for PoCXP
136 W total PoCXP output power
148 W
PoCXP output voltage 23 24 25 V
Power conversion efficiency 92.5 %
NOTE
The sense input of the PEG connector is intended for power source cable
presence detection. It should be grounded at the power supply level.
NOTE
The power rating of the power source is application dependent.
