Logical map
The state of the port is reported as follows:
Relative V+/V- voltage Logical State
V+ > V- HIGH
V+ < V- LOW
Unconnected input HIGH
Compatible drivers
The following drivers are compatible with the high-speed differential input ports:
● RS-422/RS-485 differential line drivers
● Complementary TTL drivers
