84
AC characteristics
Driver
Parameter Min. Typ. Max. Units
Pulse width 50 ns
Pulse rate 0 10 MHz
10%-90% rise/fall time TBD µs
Receiver
Parameter Min. Typ. Max. Units
Pulse width 50 ns
Pulse rate 0 10 MHz
10%-90% rise/fall time TBD µs
Logical map
The state of the port is as follows:
Relative V+/V- voltage Logical State
V+ > V- HIGH
V+ < V- LOW
Compatible sources
Sources with the following drivers are compatible:
● RS-422 differential line drivers
● Complementary TTL drivers
Compatible loads
Loads with the following receivers are compatible:
● RS-422 differential line receivers
Coaxlink Hardware Manual
