87
Logical Map
The state of the port is reported as follows:
Input voltage Logical State
VIN > 2.0 V HIGH
VIN < 0.8 V LOW
Unconnected input port Undetermined
Compatible sources
Sources with the following drivers are compatible:
□ LVTTL ( 3.3 V low-voltage TTL)
□ TTL (5 V TTL)
□ CMOS (5 V CMOS)
Compatible loads
Loads with the following receivers are compatible:
□ LVTTL ( 3.3 V low-voltage TTL)
□ TTL (5 V TTL)
Coaxlink Hardware Manual
