DC characteristics
Parameter Conditions Min. Typ. Max. Units
ESD protection Human Body Model (HBM) 2 kV
NOTE
The I/O port includes a latch-up protection.
Driver
Parameter Conditions Min. Typ. Max. Units
Low-level output current 64 mA
Low-level output voltage
@ 8 mA 0.34 0.36 V
@ 16 mA 0.48 0.55 V
@ 32 mA 0.78 0.81 V
@ 64 mA 1.34 1.36 V
High-level output current -32 mA
High-level output voltage
@-8 mA; (1) 2.60 3.00 V
@-16 mA; (1) 2.20 2.70 V
@-32 mA; (1) 1.75 2.20 V
ESD protection Human Body Model (HBM) 2 kV
Condition (1): 300 Ohms line termination resistor to GND.
Receiver
Parameter Conditions Min. Typ. Max. Units
Absolute maximum voltage rating 0 5 V
