92
DC characteristics
Parameter Conditions Min. Typ. Max. Units
ESD protection Human Body Model (HBM) 2 kV
NOTE
The I/O port includes a latch-up protection.
Driver
Parameter Conditions Min. Typ. Max. Units
Absolute maximum voltage rating 0 5 V
Low-level output current 24 mA
Low-level output voltage
@50µA 0.001 0.1 V
@ 24 mA 0.81 V
High-level output current -24 mA
High-level output voltage
@-50 µA; (1) 4.9 4.99 V
@-24 mA; (1) 3.89 V
Condition (1): 300 Ohms line termination resistor to GND.
Receiver
Parameter Conditions Min. Typ. Max. Units
Absolute maximum voltage rating 0 5 V
AC characteristics
Driver
Parameter Conditions Min. Typ. Max. Units
Pulse width 500 ns
Pulse rate 0 1 MHz
10%-90% rise/fall time TBD ns
Receiver
Parameter Conditions Min. Typ. Max. Units
Pulse width 500 ns
Pulse rate 0 1 MHz
10%-90% rise/fall time TBD ns
