EUROCOM M22ES - Page 29

Disassembly
Disassembly Steps 2 - 5
2.Disassembly
To remove the Mainboard:
1. Remove the battery page 2 - 6
2. Remove the keyboard page 2 - 8
3. Remove the HDD page 2 - 9
4. Remove the CPU page 2 - 10
5. Remove the modem page 2 - 12
6. Remove the CD device page 2 - 12
7. Remove the bottom case page 2 - 13
8. Remove the FDD page 2 - 15
9. Remove the mainboard page 2 - 16
To remove the Inverter:
1. Remove the battery page 2 - 6
2. Remove the keyboard page 2 - 8
3. Remove the HDD page 2 - 9
4. Remove the CPU page 2 - 10
5. Remove the modem page 2 - 12
6. Remove the CD device page 2 - 12
7. Remove the bottom case page 2 - 13
8. Remove the inverter page 2 - 17
To remove the LCD Panel:
1. Remove the battery page 2 - 6
2. Remove the keyboard page 2 - 8
3. Remove the HDD page 2 - 9
4. Remove the CPU page 2 - 10
5. Remove the modem page 2 - 12
6. Remove the CD device page 2 - 12
7. Remove the bottom case page 2 - 13
8. Remove the inverter page 2 - 17
9. Remove the LCD page 2 - 18
