Connectors and LEDs
Issue C
61
Pin Signal name Pin Signal name
A58 PCIE_TX3+ (PCIE switch port 7) B58 PCIE_RX3+ (PCIE switch port 7)
A59 PCIE_TX3- (PCIE switch port 7) B59 PCIE_RX3- (PCIE switch port 7)
A60 GND B60 GND
A61 PCIE_TX2+ (PCIE switch port 6) B61 PCIE_RX2+ (PCIE switch port 6)
A62 PCIE_TX2- (PCIE switch port 6) B62 PCIE_RX2- (PCIE switch port 6)
A63 GPI1(CPLD) B63 GPO3 (SuperIO: GP51)
A64 PCIE_TX1+ (PCIE switch port 5) B64 PCIE_RX1+ (PCIE switch port 5)
A65 PCIE_TX1- (PCIE switch port 5) B65 PCIE_RX1- (PCIE switch port 5)
A66 GND B66 WAKE0#
6
(in)
A67 GPI2 (SuperIO: GP61) B67 WAKE1#
6
(in)
A68 PCIE_TX0+ (SCH US15W port 1) B68 PCIE_RX0+ (SCH US15W port 1)
A69 PCIE_TX0- (SCH US15W port 1) B69 PCIE_RX0- (SCH US15W port 1)
A70 GND B70 GND
A71 LVDS_A0+ (SCH US15W LVDS) B71 NC (PROTEUS V1I1: LVDS_B0+)
A72 LVDS_A0- (SCH US15W LVDS) B72 NC (PROTEUS V1I1: LVDS_B0-)
A73 LVDS_A1+ (SCH US15W LVDS) B73 NC (PROTEUS V1I1: LVDS_B1+)
A74 LVDS_A1- (SCH US15W LVDS) B74 NC (PROTEUS V1I1: LVDS_B1-)
A75 LVDS_A2+ (SCH US15W LVDS) B75 NC (PROTEUS V1I1: LVDS_B2+)
A76 LVDS_A2- (SCH US15W LVDS) B76 NC (PROTEUS V1I1: LVDS_B2-)
A77
LVDS_VDD_EN (SCH US15W
LVDS)
B77 NC (PROTEUS V1I1: LVDS_B3+)
A78 LVDS_A3+ (SCH US15W LVDS) B78 NC (PROTEUS V1I1: LVDS_B3-)
A79 LVDS_A3- (SCH US15W LVDS) B79
LVDS_BKLT_EN (out) (SCH
US15W LVDS)
A80 GND B80 GND
A81
LVDS_A_CK+ (SCH US15W
LVDS)
B81
NC (PROTEUS V1I1:
LVDS_B_CK+)
A82
LVDS_A_CK- (SCH US15W
LVDS)
B82
NC (PROTEUS V1I1:
LVDS_B_CK-)
A83
LVDS_I2C_CK (out) (SCH
US15W LVDS)
B83
LVDS_BKLT_CTRL (out) (SCH
US15W LVDS)
A84
LVDS_I2C_DAT (in/out) (SCH
US15W LVDS)
B84
VCC_5V_SBY (+5V standby
power)
continued…
6
PCIE_WAKE_MINI# = WAKE0# AND WAKE1# PCIE_WAKE_MINI# is connected to SCH US15W WAKE# or EC
LPC2132 (build option).
