Feature Description
Electrical safety
Integrated RCBO 40 A for 30 mA AC leakage detection
per outlet.
CCID 6 mA DC leakage detection per outlet.
RCBO type
2 x Schrack AK667840, Type A, characteristic C, 6 kA,
3+N, 40 A
Surge protection 4 kV.
Black-out protection Return to previous status after power loss.
Operating temperature range -25 °C to +45 °C.
Operating humidity (non-regulating) 85 % at 50 °C (non-condensing).
Maximum installation altitude 2000 m above sea level.
Enclosure degree of protection IP55 / IK10 / IEC 60529.
Certification
IEC 61851-1 (2017), IEC 61851- 21-2 (2018), IEC 61000-3-2
(2014), IEC 61000-3-3 (2013), EN 301 489-1 V2.2.0, EN
301 489-3 V2.1.1, EN 301 489-17 V3.2.0, EN 301 489-52
V1.1.0, EN 301 908- 1 V11.1.1, EN 301 511 V12.5.1, EN
300 330 V2.1.1, EN 300 328 V2.1.1, EN 301 893 V2.1.1,
EN 300 220-1 V3.1.1, EN 300 220- 2 V3.1.1, CE
conformity, RoHS, REACH.
Connectivity
Authorization RFID and QR code.
Communication standard
Dual band Wi-Fi 2.4/5 GHz, Bluetooth 4.0 for
configuration with the EVBox Connect app, GPS.
Communication protocol to backend OCPP 1.5 S / 1.6 S / 1.6 J.
Smart Charging using the MAX
protocol
RS485.
Charging station configuration Using EVBox Connect app.
Physical properties
Plastic materials ISO 3795 passed, DIN 53438 F1/K1.
EN
3. Product features
12
